    CLEVIS END FITTING

    CROSBY - Chain Clevis End Fittings

    Product Details

    BENEFITS S-1317 Clevis Sling Hook
    • Forged alloy steel — Quenched & Tempered.
    • Individually Proof Tested to 2-1/2 times the Working Load Limit with certification.
    • Recessed trigger design is flush with the hook body, protecting the trigger from potential damage.
    • Easy to operate with enlarged thumb access.
    • Positive Lock Latch is self-locking when hook is loaded.
    • Eye style is designed with engineered flat to connect to S-1325 chain coupler.
    • Suitable for use with Grade 100 and Grade 80 chain.
    • The SHUR-LOC® hook, if properly installed and locked, can be used for personnel lifting applications and meets the intent of OSHA Rule 1926.1431(g) (1)(i)(A) and 1926.1501(g)(4)(iv)(B).
    • Fatigue rated to 20,000 cycles at 1-1/2 times the Working Load Limit.
    BENEFITS A-1338 Cradle Grab Hook
    • Forged alloy steel — Quenched & Tempered.
    • Innovative cradle design allows for 100% efficiency of Grade 100 chain.
    • Individually Proof Tested to 2-1/2 times the Working Load Limit with certification.
    • Each hook has a Product Identification Code (PIC) for material traceability, along with the size and the name Crosby.
    • Suitable for use with Grade 100 and Grade 80 chain.
    • The use of A-1338 Cradle Grab Hook will allow 100 percent of the chain sling capacity. When used to hook back to chain leg to form a choker, the angle of the choke must be 120 degrees or greater. When used as a chain shortener, minimize twist of chain and ensure chain is fully engaged in hook.
    • Fatigue rated to 20,000 cycles at 1-1/2 times the Working Load Limit.
    BENEFITS A-1358 Grab Hook
    • Forged alloy steel — Quenched & Tempered.
    • Individually Proof Tested to 2-1/2 times the Working Load Limit with certification.
    • Each hook has a Product Identification Code (PIC) for material traceability, along with the size and the name Crosby.
    • Suitable for use with Grade 100 and Grade 80 chain.
    • Fatigue rated to 20,000 cycles at 1-1/2 times the Working Load Limit.
    BENEFITS A-1359 Clevis Foundry Hook
    • Forged alloy steel — Quenched & Tempered.
    • Individually Proof Tested to 2-1/2 times the Working Load Limit with certification.
    • Each hook has a Product Identification Code (PIC) for material traceability, along with the size and the name Crosby.
    • Suitable for use with Grade 100 and Grade 80 chain.
    • Fatigue rated to 20,000 cycles at 1-1/2 times the Working Load Limit.
    • Hook can be tip loaded at the reduced Working Load Limit, see below.
    • Operator must ensure the load is retained properly in the hook.
    BENEFITS L-1359 Clevis Sling Hook
    • Forged alloy steel — Quenched & Tempered.
    • Individually Proof Tested to 2-1/2 times the Working Load Limit with certification.
    • Each hook has a Product Identification Code (PIC) for material traceability, along with the size and the name Crosby.
    • Suitable for use with Grade 100 and Grade 80 chain.
    • Fatigue rated to 20,000 cycles at 1-1/2 times the Working Load Limit.
    • Hook can be tip loaded at the reduced Working Load Limit, see below.
    • Operator must ensure the load is retained properly in the hook.



    For more information contact us

    Specification

    Specification

    zoom

    PLEASE FILL PRODUCT QUESTIONAIRE FORM FOR DETAILS
