    MOORING SPELTER SOCKETS G-517

    Product Details

    FEATURE & BENEFIT
    • Wide range of sizes available:
      1-1/4” thru 4” Wireline
    • “M-Line” socket terminations have a 100% efficiency rating, based on the catalog strength of the wire rope. Ratings are based on recommended use with 6 x 7, 6 x 19, or 6 x 37 IPS or XIP (EIP), XXIP (EEIP), RRL, FC, or IWRC wire rope. Strand constructed with minimal number of wires (e.g. 1 x 7) requires special consideration that socket basket length be five (5) times the strand diameter or fifty (50) times the wire diameter, whichever is the greater.
    • Galvanized finish.
    • Designed for today’s higher strength classes of wire rope.
    • Design of bail allows for easy connection to shackles and other connecting links.
    • Socket design utilizes features to keep cone from rotating.
    • Type approved and Certification in accordance with DNV’s Rules for Certifications of Lifting Appliances, 2011 - DNV’s Offshore Standard DNVOS-E101, Drilling Plant, October 2009.



    For more information contact us

    Specification

    Specification
